8 Channel Electronic Crossover System - Pyramid CR82

Crossovers allow users to adjust the frequency at a customized sweetspot. This CR82 has a selectable lowpass crossover at 50hz, 90hz, 180hz, and a Subwoofer Bass Boost +12DB at 45hz, 80Hz, 120Hz. Can be hooked up with either High Level Inputs or Low Level Inputs - Connect via Rca cables for easy install

---

---

8 Channel Electronic Crossover System
Single Channel Input per Unit Remote Mount Unit 8 Channel Crossover System (4 Channel) Seperate Line Input for Subwoofer Channel Subwoofer Low Pass Filter 45/80/120Hz Selectable Subwoofer Octave Slope Adjustment 12/18dB Subwoofer Output Level Adjustment Variable Subwoofer Boost 0-12dB at 40Hz Subwoofer Phase Shift 0/180 Degrees Subwoofer Stereo/Mono Switch Low Pass Channel 50/90/180 Selectable Bandpass Channel 50/90/180 Flat to 2k/4k/6k High Pass Channel 2k/4k/6k Flat Selectable Octave Slope for Low Pass 12/18dB Selectable Stereo/Mono for Low Pass Channel Individual Output Level Controls for Each Channel Heavy Duty Metal Cabinet Built-in Fuse Protection DC to DC Isolated Power Supply Dimensions: 8”L x 6.5”W x 1.5”H
Brand	Pyramid
Category	Crossovers
Series	Pro Series
MSRP	$78.00
Warranty	2 Year
Item Manual	NA
