ALFA ROMEO APPLICATION GUIDE


Speaker Locations:
  • A. ~Top Dash~ B. ~Front Dash~ C. ~Kick Panel~ D. ~Upper Door~
  • E. ~Lower Door~ F. ~Behind Seat (Truck)~ G.~Lower Rear~ H. ~Upper Rear~
  • I. ~Rear Side Panel~ J. ~Rear Deck~(Trucks) K. ~Rear Sides~ L. ~Tail Sides~
  • M.~Rear Door~(Wagons, Vans)N.~Rear Top~ O.~Rear Posts (Trucks)~
    MODEL YEAR INSTALLATION Dash Stereo Kits

    WIRE HARNESS

    ANTENNA-ADAPTOR

    SPEAKER ACC

    CAR SPEAKERS
     ALFA ROMEO    to car harness  to stock radio TO-CAR RADIO FROM-CAR RADIO FRONT REAR
    GTV6 80-86 N/R N/A N/A N/R N/R   5"E 5,6"J
    MILANO 87-89 UI-K1400* UI-K777CL* N/A N/A N/R N/R   4"X6"E 5.25"J
    SEDAN 73-85 N/R N/A N/A N/R N/R   4"E 5"X7"J
    SPIDER 73-94 UI-K1400* UI-K777CL* N/A N/A N/R N/R   5.25"E SM-J
    SPRINT,VELOCE,COUPE 75-91 UI-K1400* UI-K777CL* N/A N/A N/R N/R   5"E SM-J
    SPORTSEDAN 79-82 UI-K1400* UI-K777CL* N/A N/A N/R N/R   4"X6"E 4"K
    77SEDAN 86-89 UI-K1400* UI-K777CL* N/A N/A N/R N/R   4"X6"E 4"J
    164 91-94 UI-K1400* UI-K777CL* N/A N/A N/R N/R   4"E 5.25"J
    2000 73-89 UI-K1400* UI-K777CL* N/A N/A N/R N/R   5.25"E SM-J
